| Description: | The Neomounts DS60-425BL2 NEXT Lite is a full motion desk mount for two screens up to 27" with a maximum weight capacity of 8 kg per screen. The versatile tilt (120°), rotate (360°) and swivel (180°) technology allows you to adjust the mount to the optimal viewing angle for your screens. Additionally, the mount has manual height and depth adjustment to create the perfect working position.
Due to the short T-RexĀ® upper arm of the NEXT Lite, only minimal depth is required when placed near a wall or separation panel. This allows the screens to be positioned further away from the user which is better for the eyes and also leaves more space for good ergonomic working posture. The smart internal cable management system ensures orderly routing of the cables. The DS60-425BL2 is suitable for screens that meet VESA hole pattern 75x75 or 100x100 mm. Neomounts offers various optional VESA adapter plates for deviating hole patterns. The DS60-425BL2 is equipped with an Easy-release VESA system for easy insta |
| Vendor homepage: | https://www.neomounts.com/default.asp?pageid=44&artdetail=DS60-425BL2 |
| Model: | DS60-425BL2 |
| Units per shipping box: | 4 |
| Unit calculated volume: | 0.01139 |
| Unit calculated weight: | 4.58 |
| Unit box height: | 0.105 |
| Unit box length: | 0.44 |
| Unit box width: | 0.21 |
| Swivelling: | Jā |
| Tilt angle range: | -30 - 90 |
| Width adjustment: | 332 |
| Accepts padlock: | No |
| Summary: | Neomounts DS60-425BL2 Monitor arm 17-27" - space saving. Mounting: Clamp/Grommet, Maximum weight capacity: 8 kg, Minimum screen size: 43.2 cm (17"), Maximum screen size: 68.6 cm (27"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -90 - 90°, Tilt angle range: -30 - 90°. Product colour: Black |
| Clamp mount desk thickness (max): | 80 |
| Desk thickness (max): | 80 |
| Products per pallet (eu): | 84 |
| Housing material: | Steel |
| Orientation: | Landscape/Portrait |
| Product colour: | Black |
| Depth: | 460 |
| Height: | 763 |
| Weight: | 3780 |
| Width: | 888 |
| Package depth: | 105 |
| Package height: | 440 |
| Package net weight: | 4600 |
| Package weight: | 4600 |
| Package width: | 210 |
| Quantity per pack: | 1 |
| Clamp included: | Jā |
| Vesa mount included: | Jā |
| Width adjustment range: | 0 - 332 |
| Country of origin: | China |
| Harmonized system (hs) code: | 7326909890 |
| Master (outer) case gross weight: | 18400 |
| Master (outer) case height: | 455 |
| Master (outer) case length: | 435 |
| Master (outer) case net weight: | 15100 |
| Master (outer) case width: | 220 |
| Products per master (outer) case: | 4 |
| Desk thickness (min): | 10 |
| Distance to the wall (max): | 460 |
| Distance to the wall (min): | 128 |
| Grommet mount desk thickness (max): | 40 |
| Maximum screen size: | 27 |
| Maximum vesa mount: | 100 x 100 |
| Maximum weight capacity: | 8 |
| Maximum weight capacity (per display): | 8 |
| Minimum screen size: | 17 |
| Minimum vesa mount: | 75 x 75 |
| Mounting: | Clamp/Grommet |
| Mounting type: | Desk |
| Number of displays supported: | 2 |
| Panel mounting interface: | 100 x 100/75 x 75 |
| Adjustable depth: | Jā |
| Angle of rotation: | 360 |
| Cable management: | Jā |
| Depth adjustment range: | 66 - 398 |
| Feet: | Jā |
| Feet colour: | Black |
| Height adjustment: | Jā |
| Height adjustment range: | 295 - 607 |
| Height adjustment type: | Manual |
| Swivel angle range: | -90 - 90 |
