| Description: | On the surface, the new Chateau is very similair to the previous models. We had a fantastic LTE18 launch with our partners at LMT – the leading mobile operator in Latvia. Our Chateau replaced the usual brands – and the client satisfaction skyrocketed. Most users appreciated better speed and stability, as well as the abundance of useful RouterOS features and general flexibility. And don’t forget the elegant look that fits right in anywhere – from traditional homes and luxury residences to modern office and corporate environments.
The next obvious step in the Chateau series was perfecting the wireless capabilities. With the Generation6 802.11ax wireless standard and Wave 2 support, Chateau LTE18 ax can deliver unprecedented speed. If we compare it to the previous generation, we’re looking at up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum! We’ve made massive improvements to the wireless radio and antennas. Chateau LTE18 ax supports MIMO 4x4 on LTE. Th |
| Model: | S53UG+5HaxD2HaxD-TC&EG18-EA |
| Model name: | Chateau LTE18 ax |
| Wi-fi standards: | 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax) |
| Vendor homepage: | https://mikrotik.com/product/chateaulte18_ax#fndtn-specifications |
| Units per shipping box: | 5 |
| Unit calculated volume: | 0.008064 |
| Unit calculated weight: | 1.3 |
| Wi-fi band: | Dual-band (2.4 GHz / 5 GHz) |
| Unit box height: | 0.245 |
| Unit box length: | 0.345 |
| Unit box width: | 0.075 |
| Wall mountable: | Jā |
| Ac adapter included: | Jā |
| Cables included: | UTP |
| Certification: | CE, EAC |
| Compliance certificates: | RoHS |
| Antenna design: | External |
| Wlan data transfer rate (first band): | 574 |
| Wlan data transfer rate (max): | 1200 |
| Wlan data transfer rate (second band): | 1200 |
| 3g/4g usb modem compatibility: | Jā |
| Ethernet wan: | Jā |
| Sim card slot: | Jā |
| Wan connection type: | RJ-45 |
| Cabling technology: | 10/100/1000Base-T(X) |
| Ethernet lan: | Jā |
| Ethernet lan data rates: | 2500 |
| Ethernet lan interface type: | Ethernet |
| Networking standards: | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n |
| 4g bands supported: | 1800/2100/2300/2500/2600/700/800/850/900 |
| 4g standard: | LTE-TDD & LTE-FDD |
| Gsm bands supported: | 1800/2100/850/900 |
| Mobile network generation: | 4G |
| Short message service (sms): | Jā |
| Sim card type: | MicroSIM |
| Dc-in jack: | Jā |
| Ethernet lan (rj-45) ports: | 4 |
| Usb 2.0 ports quantity: | 1 |
| Usb port: | Jā |
| Quality of service (qos) support: | Jā |
| Reset button: | Jā |
| Product colour: | White |
| Product type: | Tabletop router |
| Top wi-fi standard: | Wi-Fi 6 (802.11ax) |
| Summary: | Mikrotik Chateau LTE18 ax. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1200 Mbit/s. Ethernet LAN interface type: Ethernet, Ethernet LAN data rates: 2500 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Mobile network generation: 4G, 4G standard: LTE-TDD & LTE-FDD, GSM bands supported: 850,900,1800,2100 MHz. Product type: Tabletop router, Product colour: White |
| Antenna gain level (max): | 6 |
| Antennas quantity: | 2 |
| Built-in processor: | Jā |
| Flash memory: | 128 |
| Internal memory: | 128 |
| Processor cores: | 4 |
| Processor frequency: | 864 |
| Ram capacity (wi-fi point): | 1000 |
| External power adapter: | Jā |
| Output voltage: | 12 - 28 |
| Power consumption (typical): | 16 |
| Power source type: | DC |
| Operating temperature (t-t): | -40 - 65 |
| Depth: | 156 |
| Height: | 44 |
| Width: | 240 |
| Units per pallet: | Nav |
