Kingston 8GB 3200MHz DDR4 CL22 DIMM

This product is not available in leasing.

Delivery costs:

In our office	for free
Riga	5.69 EUR
Riga district	7.11 EUR
Regional centers	8.54 EUR
Rest of the Latvia	8.54 EUR
	3.56 EUR

98.18

Price to 2026-06-04
In stock: 8
Last time product information was updated:
2026-06-03 21:21

Quantity:

Gallery

Apraksts

DDR4|8GB|Number of modules 1|3200 MHz|288-pin DIMM|CL 22|Memory timings 22-22-22|Nominal voltage 1.2 V|Chip Organization 1024Mx64

Ražotāja kods:

KVR32N22S8/8

Parameters - Kingston 8GB 3200MHz DDR4 CL22 DIMM

Vendor homepage:	https://www.kingston.com/en
Memory form factor:	288-pin DIMM
Memory layout (modules x size):	1 x 8
Memory ranking:	1
Programming power voltage (vpp):	2.5
Refresh row cycle time:	350
Memory voltage:	1.2
Module configuration:	1024M x 64
Memory data transfer rate:	3200
Lead plating:	Gold
Jedec standard:	Jā
Component for:	PC/Server
Country of origin:	Taiwan
Ecc:	No
Internal memory:	8
Internal memory type:	DDR4
Cas latency:	22
Unit calculated weight:	0.03
Buffered memory type:	Unregistered (unbuffered)
Row active time:	32
Row cycle time:	45.75
Operating temperature (t-t):	0 - 85
Storage temperature (t-t):	-55 - 100
Compliance certificates:	RoHS
Doesn't contain:	Halogen
Height:	31.25
Width:	133.35
Harmonized system (hs) code:	84733020
Units per shipping box:	1
Unit box width:	0.045
Summary:	Kingston Technology ValueRAM . Component for: PC/Server, Internal memory: 8 GB, Memory layout (modules x size): 1 x 8 GB, Internal memory type: DDR4, Memory form factor: 288-pin DIMM, CAS latency: 22
Cncode:	84733020
Unit calculated volume:	5.76e-005
Unit box length:	0.16
Unit box height:	0.008
Description:	ValueRAM's KVR32N22S8/8 is a 1G x 64-bit (8GB) DDR4-3200 CL22 SDRAM (Synchronous DRAM), 1Rx8, memory module, based on eight 1G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR4-3200 timing of 22-22-22 at 1.2V. Each 288-pin DIMM uses gold contact fingers. Nominal and dynamic on-die termination (ODT) for data, strobe, and mask signals Low-power auto self refresh (LPASR) Data bus inversion (DBI) for data bus On-die VREFDQ generation and calibration Single-rank On-board I2 serial presence-detect (SPD) EEPROM 16 internal banks; 4 groups of 4 banks each Fixed burst chop (BC) of 4 and burst length (BL) of 8 via the mode register set (MRS) Selectable BC4 or BL8 on-the-fly (OTF) Fly-by topology Terminated control command and address bus RoHS Compliant and Halogen-Free
