Dahua technology co., ltd 4K IP Network Camera 5MP HDW3549H-AS-PV-S4 2.8

Camera

Image Sensor

1/2.7" CMOS

Max. Resolution

2960 (H) × 1668 (V)

ROM

128 MB

RAM

512 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.003 [email protected] (Color, 30 IRE)
0.0003 [email protected] (B/W, 30 IRE)
0 lux (illuminator on)

S/N Ratio

? 56 dB

Illumination Distance

Up to 30 m (98.43 ft) (IR)
Up to 30 m (98.43 ft) (warm light)

Illuminator On/Off Control

Auto; manual

Illuminator Number

1 (IR LED)
1 (warm light)

Angle Adjustment

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

2.8 mm

Field of View

2.8 mm: H: 97°; V: 70°; D: 128°

Iris Type

Fixed

Close Focus Distance

2.8 mm: 1.5 m (4.92 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm
