| Windows studio effects support: | Jā |
| Unit box height: | 0.045 |
| Unit calculated weight: | 0.115 |
| Units per shipping box: | 5 |
| Intel virtualization technology (vt-x): | Jā |
| Unit box width: | 0.102 |
| Unit box length: | 0.116 |
| On-board graphics card id: | 0x7D67 |
| Processor operating modes: | 64-bit |
| Intel vt-x with extended page tables (ept): | Jā |
| Number of displays supported (on-board graphics): | 4 |
| On-board graphics card: | Jā |
| On-board graphics card base frequency: | 300 |
| Unit calculated volume: | 0.0007488 |
| Enhanced intel speedstep technology: | Jā |
| Intel 64: | Jā |
| Intel trusted execution technology: | Jā |
| Vendor homepage: | https://ark.intel.com/content/www/us/en/ark/products/241067/intel-core-ultra-5-processor-245k-24m-cache-up-to-5-20-ghz.html |
| Cpu family name: | Intel Core Ultra |
| Model number: | U5-245K |
| Processor boost frequency: | 5.2 |
| Mode-based execute control (mbe): | Jā |
| Processor socket: | LGA 1851 (Socket V1) |
| Intel virtualization technology for directed i/o (vt-d): | Jā |
| Summary: | Intel Core Ultra 5 245K. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Box. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 30 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: Intel Graphics, On-board graphics card outputs supported: DisplayPort 2.1, Embedded DisplayPort (eDP) 1.4b, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0 |
| Processor cache: | 24 |
| Processor cache type: | Smart Cache |
| Processor codename: | Arrow Lake |
| Processor cores: | 14 |
| Processor family: | Intel Core Ultra 5 |
| Processor generation: | Intel Core Ultra (Series 2) |
| Processor manufacturer: | Intel |
| Processor model: | 245K |
| Units per pallet: | Nav |
| Maximum operating temperature: | 105 |
| Harmonized system (hs) code: | 8542310050 |
| Launch date: | Q4'24 |
| Memory speed (max): | 6400 |
| Opencl version: | 3.0 |
| Status: | Launched |
| Graphics output: | DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b |
| L2 cache: | 26624 |
| Maximum internal memory: | 192 |
| On-board graphics card dynamic frequency (max): | 1900 |
| On-board graphics card directx version: | 12.0 |
| Cooler included: | No |
| Efficient cores: | 8 |
| Efficient-core base frequency: | 3.6 |
| Efficient-core boost frequency: | 4.6 |
| Maximum number of dmi lanes: | 8 |
| Maximum turbo power: | 159 |
| Package type: | Box |
| Performance cores: | 6 |
| Performance-core base frequency: | 4.2 |
| Performance-core boost frequency: | 5.2 |
| Processor ark id: | 241067 |
| Processor base power: | 125 |
| Discrete graphics card: | No |
| Discrete graphics card model: | Not available |
| Ecc: | Jā |
| Maximum internal memory supported by processor: | 192 |
| Memory channels: | Dual-channel |
| Memory clock speeds supported by processor: | 6400 |
| Memory types supported by processor: | DDR5-SDRAM |
| Stepping: | B0 |
| Ai software frameworks supported by npu: | DirectML/ONNX RT/OpenVINO/WebNN/Windows ML |
| Gpu performance up to: | 8 |
| Neural processor unit (npu): | Intel AI Boost |
| Npu performance up to: | 13 |
| Sparsity support: | Jā |
| Total processor performance up to: | 30 |
| Use conditions: | PC/Client/Tablet/Workstation |
| On-board graphics card refresh rate at maximum resolution (displayport): | 60 |
| On-board graphics card refresh rate at maximum resolution (edp - integrated flat panel): | 60 |
| On-board graphics card refresh rate at maximum resolution (hdmi): | 60 |
| Xe-cores: | 4 |
| Commodity classification automated tracking system (ccats): | 740.17B1 |
| Direct media interface (dmi) revision: | 4.0 |
| Embedded options available: | No |
| Execute disable bit: | Jā |
| Export control classification number (eccn): | 5A992C |
| Idle states: | Jā |
| Market segment: | Desktop |
| Maximum number of pci express lanes: | 24 |
| Pci express slots version: | 4.0/5.0 |
| Scalability: | 1S |
| Supported instruction sets: | AVX 2.0/SSE4.1/SSE4.2 |
| Thermal monitoring technologies: | Jā |
| Thermal solution specification: | PCG 2020A |
| On-board graphics card model: | IntelĀ® Graphics |
| On-board graphics card opengl version: | 4.5 |
| On-board graphics card outputs supported: | DisplayPort 2.1/Embedded DisplayPort (eDP) 1.4b/HDMI 2.1 |
| Ai software frameworks supported by cpu: | DirectML/ONNX RT/OpenVINO/WebNN/Windows ML |
| Intel vproā® enterprise platform eligibility: | Jā |
| Intelā® active management technology (intelā® amt): | Jā |
| Intelā® aes new instructions (intelā® aes-ni): | Jā |
| Intelā® boot guard: | Jā |
| Intelā® control-flow enforcement technology (cet): | Jā |
| Intelā® deep learning boost (intelā® dl boost) on cpu: | Jā |
| Intelā® deep learning boost (intelā® dl boost) on gpu: | Jā |
| Intelā® hardware shield eligibility: | Jā |
| Intelā® one-click recovery: | Jā |
| Intelā® os guard: | Jā |
| Intelā® quick sync video technology: | Jā |
| Intelā® remote platform erase (rpe): | Jā |
| Intelā® secure key: | Jā |
| Intelā® speed shift technology: | Jā |
| Intelā® stable it platform program (sipp): | Jā |
| Intelā® standard manageability (ism): | Jā |
| Intelā® thread director: | Jā |
| Intelā® threat detection technology (tdt): | Jā |
| Intelā® thunderbolt 4: | Jā |
| Intelā® total memory encryption - multi key: | Jā |
| Intelā® turbo boost technology: | 2.0 |
| Intelā® virtualization technology with redirect protection (vt-rp): | Jā |
| Intelā® volume management device (vmd): | Jā |
