Power Supply|CHIEFTEC|500 Watts|Efficiency 80 PLUS GOLD|PFC Active|BBS-500S

This product is not available in leasing.

Delivery costs:

In our office	for free
Riga	5.69 EUR
Riga district	7.11 EUR
Regional centers	8.54 EUR
Rest of the Latvia	8.54 EUR
	3.56 EUR

55.49

Price to 2026-07-14
In stock: 50
Last time product information was updated:
2026-07-14 17:32

Quantity:

Gallery

Apraksts

Ražotāja kods:

BBS-500S

Parameters - Power Supply|CHIEFTEC|500 Watts|Efficiency 80 PLUS GOLD|PFC Active|BBS-500S

Max output current (+5vsb):	2.5
Vendor homepage:	https://www.chieftec.eu/products-detail/113/CORE_SERIES
Width:	140
Package weight:	2060
Harmonized system (hs) code:	84733020
80 plus certification:	80 PLUS Gold
Weight:	1650
Max output current (-12v):	0.3
Power factor correction (pfc) type:	Active
Power protection features:	Over voltage/Overload/Short circuit
Total power:	500
Floppy drive power connector:	1
Floppy disk drive connector:	Jā
Cabling type:	Non-Modular
Cpu power cable length:	650
Cpu power connector (4+4 pin):	Jā
Motherboard power connector:	24-pin ATX
Number of sata power connectors:	4
Pci express power cable length:	500
Pci express power connectors (6+2 pin):	1
Units per pallet:	Nav
Summary:	Chieftec Core BBS-500S. Total power: 500 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, SATA power cable length: 150,500 mm, Peripheral (Molex) power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: PS/2, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 140 mm, Depth: 150 mm, Height: 86 mm
Input current:	8
Max output current (+12v1):	41
Max output current (+3.3v):	18
Max output current (+5v):	18
Unit box height:	0.105
Ac input frequency:	47 - 63
Unit calculated weight:	2.1
Ac input voltage:	100 - 240
Combined power (+5vsb):	12.5
Combined power (-12v):	3.6
Model name:	BBS-500S
Units per shipping box:	4
Unit box width:	0.185
Unit calculated volume:	0.006107
Unit box length:	0.24
Description:	With the Core Series, Chieftec will be bringing a new 80 PLUS Gold certified PSU to market, offering the best possible value-formoney. The goal of the Core Series power-supplies is to deliver a no-nonsense package of performance, efficiency and reliability. With power output ranging from 500W to 700W, this product is idea for customers who want top-tier power output at the most attractive price. 80 PLUS Gold Efficiency Compact size with only 140mm depth 500-700W power output Motherboard, CPU and PCI-E cable lengths of 650mm
Height:	86
Depth:	150
Product colour:	Black
Number of fans:	1
Fan diameter:	120
Cooling type:	Active
Purpose:	PC
Power supply unit (psu) form factor:	PS/2
Atx version:	2.3
Sata power cable length:	150/500
Peripheral (molex) power connectors (4-pin):	3
Peripheral (molex) power cable length:	150/500
